Share • LinkedIn • Facebook • Twitter 1 Can't get AutoCAD to hatch an area? As frequently as this happens, I could have just titled this article 'Using Hatch in AutoCAD'. Among the mysteries of the universe is why a program that can build a scale 3-D model of the solar system cannot seamlessly perform some of the same functions that my Super Nintendo did in Mario Paint.

An even bigger mystery is how to explain to your non-CAD coworkers why it took all afternoon to color a map. Nevertheless, here are some tried-and-true 'solutions': • Before hatching, do whatever you need to do to cut down the amount of data going on in your drawing. PURGE out anything you don't need. If you're one of those lazy users that always reuses the same file, and has ten different projects off to the side in model space, delete them and PURGE again. Adobe photoshop cc for mac telecharger. And turn off any layers you won't need during the hatching command. • Draw a polygon around the area to be hatched, and delete it afterward. This doesn't actually make hatch work any better, but it's a good failsafe to practice in case your area doesn't hatch correctly.

Instead of having hatch extend all the way to gosh-knows-where, it will only extend to the edge of the polygon, saving you a ton of time and a possible freeze. Epson xp-200 install for mac. • REGEN religiously.

• Pan out until you can see the entire area that will be hatched. This will help CAD process. • Start with a simple pattern, then edit the pattern once you've finished hatching.

Try something like 'DOTS' set to a scale of 1.00. AutoCAD won't get as confused trying to find the edges of the area, and once you have the hatch in place you can change it to look however you want. • Change the Gap Tolerance setting. Type HATCH then T to access settings.

You can then increase the gap tolerance. Honestly, it's never helped me, but theoretically it should. • Cut and paste the area to be hatched into a separate DWG. After copying, open a new blank DWG. Right click and select Clipboard --> paste to original coordinates. PURGE to get rid of unnecessary stuff that may have come in with it. Then hatch, copy the hatch, and again paste to original coordinates.
